EC-05
Wire Marker Sleeves
This product is intended for wire-harness manufacturers, equipment wiring, panel assembly and electrical-installation teams.
Request pricing for EC-05
Product overview
What this product covers
This product is intended for wire-harness manufacturers, equipment wiring, panel assembly and electrical-installation teams. The marker follows wire through cut, sleeve, termination, continuity test and assembly, with identity matching drawing, wire list and endpoints. Select heat-shrink, sleeve, wrap or flag from diameter, termination sequence, bend and reading space before print. Pre-cut or continuous non-adhesive sleeves for sliding onto wires before termination. Wire marker sleeves identify conductors without adhesive contact. Inside diameter, wall, sleeve length and wire installation sequence are confirmed against the wire and terminal assembly. The sleeve is mechanically retained by fit and termination rather than adhesive or heat recovery. Zheye controls metal plates, layout and variable data; polyimide, polyester and wire-marker materials are sourced by declared construction and process class. This page presents one standard model, EC-05-VINYL, in Flexible PVC. Dimensions, processes and acceptance notes on this page refer to this representative construction.
Applications
- Panel wiring
- Harness assembly
- Terminal connections
Buyers and teams
- wire-harness manufacturers, equipment wiring, panel assembly and electrical-installation teams
Materials
- Flexible PVC
Marking
- Printed circuit code
- Colour coding
- Sequential references
Installation
- Slide onto wire before termination
Specifications
| Field | Documented value |
|---|---|
| Wire range | Outside diameter and insulation |
| Sleeve ID | Slip fit before termination |
| Length | Identifier and readability |
| Supply | Pre-cut, continuous or carrier format |
Recommended project inputs
- Wire Marker Sleeves; wire list and endpoint data, diameter, termination sequence, environment, printer, quantity and kit grouping.
- State the identified object, material/surface, available space, orientation, holes/ties/adhesive/matched tool and provide a site photo where possible.
- Provide length, width/diameter, thickness, corners/edges, holes/slots, fit tolerances and any keep-clear or no-adhesive zones.
- Supply final text, units, graphics, colour, language, serial/barcode/RFID rule, human-readable data and one approved revision; numbers shown in sample images are never treated as production data.
- State temperature and dwell, indoor/outdoor use, UV, water, oil, cleaner/chemical, abrasion, vibration, read conditions or other real exposure together with test method and pass/fail criterion.
- Provide prototype and production quantity, start/end and permitted-gap rules, grouping, packing sequence, batch documents and target delivery.
- Where regulation, certification, permit, ethics, brand authorisation or customer specification applies, provide the applicable revision and owner-approved file; a product name or image cannot replace it.
Continue with this product
Discuss Wire Marker Sleeves
Include product code EC-05 with the project inputs that apply.
