EC-09
Electronics Data Matrix Traceability Labels
This product is intended for electronics manufacturing, SMT, PCB assembly, test and quality-traceability teams.
Request pricing for EC-09
Product overview
What this product covers
This product is intended for electronics manufacturing, SMT, PCB assembly, test and quality-traceability teams. A small barcode or 2D code links PCB, subassembly and finished product to work order, lot, test and rework records. Confirm placement stage, solder or cleaning temperature, available area and scanner before stock, adhesive and symbology. High-density 2D-code labels linking boards, subassemblies and finished electronics to production records. Data Matrix traceability labels are designed from code content, cell size, print resolution, scanner optics and the available marking area. Human-readable data and revision control remain visible when space allows. The product is optimized for dense unique 2D identities and data verification rather than general electronics branding. Zheye controls metal plates, layout and variable data; polyimide, polyester and wire-marker materials are sourced by declared construction and process class. This page presents one standard model, EC-09-PI, in Polyimide. Dimensions, processes and acceptance notes on this page refer to this representative construction.
Applications
- PCB serialisation
- Subassembly tracking
- Electronics repair records
Buyers and teams
- electronics manufacturing, SMT, PCB assembly, test and quality-traceability teams
Materials
- Polyimide
Marking
- Data Matrix
- Human-readable serial
- Lot and revision
- Logo
Installation
- Pressure-sensitive adhesive
Specifications
| Field | Documented value |
|---|---|
| Code | Data Matrix content and error correction |
| Cell size | Printer and scanner verified |
| Data file | Unique serial and duplicate controls |
| Exposure | Assembly and service conditions reviewed |
Recommended project inputs
- Electronics Data Matrix Traceability Labels; PCB or assembly, placement stage, temperature and cleaning, data and symbology, print and scan equipment, size and quantity.
- State the identified object, material/surface, available space, orientation, holes/ties/adhesive/matched tool and provide a site photo where possible.
- Provide length, width/diameter, thickness, corners/edges, holes/slots, fit tolerances and any keep-clear or no-adhesive zones.
- Supply final text, units, graphics, colour, language, serial/barcode/RFID rule, human-readable data and one approved revision; numbers shown in sample images are never treated as production data.
- State temperature and dwell, indoor/outdoor use, UV, water, oil, cleaner/chemical, abrasion, vibration, read conditions or other real exposure together with test method and pass/fail criterion.
- Provide prototype and production quantity, start/end and permitted-gap rules, grouping, packing sequence, batch documents and target delivery.
- Where regulation, certification, permit, ethics, brand authorisation or customer specification applies, provide the applicable revision and owner-approved file; a product name or image cannot replace it.
Continue with this product
Discuss Electronics Data Matrix Traceability Labels
Include product code EC-09 with the project inputs that apply.
