Metal Plates & Nameplates
MP-05
Electrical Panel Nameplates
This product is intended for panel builders, switchgear manufacturers, electrical contractors and automation integrators.
Request pricing for MP-05
Product overview
What this product covers
This product is intended for panel builders, switchgear manufacturers, electrical contractors and automation integrators. Panel text must match schematics, I/O lists, circuit numbers and equipment tags for wiring, commissioning, acceptance and fault finding. Lock the device or circuit mapping, text orientation and layout first, then confirm slots, pitch, material and any sequential numbering. Panel and enclosure plates for circuits, controls, warnings and equipment references. Electrical panel nameplates provide consistent equipment references across control cabinets, switchgear and distribution systems. They can be supplied as complete panel sets with drawing references. This product is configured for panel layouts, circuit references and grouped packing rather than general equipment branding. Zheye cuts, marks and finishes metal plates from released drawings and variable-data files. This page presents one standard model, MP-05-AL-ANOD, in Anodized aluminium. Dimensions, processes and acceptance notes on this page refer to this representative construction.
Applications
- Control cabinets
- Switchgear
- Distribution panels
Buyers and teams
- panel builders, switchgear manufacturers, electrical contractors and automation integrators
Materials
- Anodized aluminium
Marking
- Laser engraving
- Mechanical engraving
- Sequential references
- Colour filling
Installation
- Screws
- Rivets
- Approved adhesive
Specifications
| Field | Documented value |
|---|---|
| Material thickness | Anodized aluminium 0.3-3.0 mm |
| Text | Circuit, function or warning |
| Set control | Packed by panel or drawing |
| Hole pattern | Optional |
| Colour | Selected by material and application |
Recommended project inputs
- Electrical Panel Nameplates; cabinet or panel drawing, electrical tag list, text and units, hole or slot dimensions, mounting, colours and quantity.
- State the identified object, material/surface, available space, orientation, holes/ties/adhesive/matched tool and provide a site photo where possible.
- Provide length, width/diameter, thickness, corners/edges, holes/slots, fit tolerances and any keep-clear or no-adhesive zones.
- Supply final text, units, graphics, colour, language, serial/barcode/RFID rule, human-readable data and one approved revision; numbers shown in sample images are never treated as production data.
- State temperature and dwell, indoor/outdoor use, UV, water, oil, cleaner/chemical, abrasion, vibration, read conditions or other real exposure together with test method and pass/fail criterion.
- Provide prototype and production quantity, start/end and permitted-gap rules, grouping, packing sequence, batch documents and target delivery.
- Where regulation, certification, permit, ethics, brand authorisation or customer specification applies, provide the applicable revision and owner-approved file; a product name or image cannot replace it.
Continue with this product
Discuss Electrical Panel Nameplates
Include product code MP-05 with the project inputs that apply.
