Metal Plates & Nameplates
MP-08
Custom-Shaped Metal Plates
This product is intended for equipment OEMs, contract manufacturers, system integrators, and retrofit or service teams.
Request pricing for MP-08
Product overview
What this product covers
This product is intended for equipment OEMs, contract manufacturers, system integrators, and retrofit or service teams. The plate follows the drawing, BOM and equipment number through assembly, FAT, delivery and service, giving operators a fixed reference for model, serial and equipment identity. Start with the equipment fields, artwork revision and numbering rule, then confirm this model's material suitability, thickness and holes or adhesive for the service environment. Non-standard plate profiles with drawing-controlled edges, holes, slots and marking areas. Custom-shaped metal plates are cut around an installation envelope, branding outline or mechanical interface. The profile and marking plan are reviewed together to preserve edge strength and readable data. Use this page when shape, holes or slots define the product more strongly than its end-use industry. Zheye cuts, marks and finishes metal plates from released drawings and variable-data files. This page presents one standard model, MP-08-AL-ANOD, in Anodized aluminium. Dimensions, processes and acceptance notes on this page refer to this representative construction.
Applications
- Branded equipment
- Restricted mounting spaces
- Replacement components
Buyers and teams
- equipment OEMs, contract manufacturers, system integrators, and retrofit or service teams
Materials
- Anodized aluminium
Marking
- Laser engraving
- Mechanical engraving
- Colour filling
- Variable data
Installation
- Custom holes or slots
- Rivets
- Screws
- Approved adhesive
Specifications
| Field | Documented value |
|---|---|
| Material thickness | Anodized aluminium 0.3-3.0 mm |
| Profile | DXF, DWG or approved drawing |
| Features | Holes, slots and radiused corners |
| Tolerance | Confirmed during drawing review |
| Marking area | Checked against profile |
Recommended project inputs
- Custom-Shaped Metal Plates; equipment type, approved drawing or sample, field list, service environment, mounting method, quantity and serial-number file.
- State the identified object, material/surface, available space, orientation, holes/ties/adhesive/matched tool and provide a site photo where possible.
- Provide length, width/diameter, thickness, corners/edges, holes/slots, fit tolerances and any keep-clear or no-adhesive zones.
- Supply final text, units, graphics, colour, language, serial/barcode/RFID rule, human-readable data and one approved revision; numbers shown in sample images are never treated as production data.
- State temperature and dwell, indoor/outdoor use, UV, water, oil, cleaner/chemical, abrasion, vibration, read conditions or other real exposure together with test method and pass/fail criterion.
- Provide prototype and production quantity, start/end and permitted-gap rules, grouping, packing sequence, batch documents and target delivery.
- Where regulation, certification, permit, ethics, brand authorisation or customer specification applies, provide the applicable revision and owner-approved file; a product name or image cannot replace it.
Continue with this product
Discuss Custom-Shaped Metal Plates
Include product code MP-08 with the project inputs that apply.
