Metal Plates & Nameplates
MP-09
Control Panel Labels
This product is intended for panel builders, switchgear manufacturers, electrical contractors and automation integrators.
Request pricing for MP-09
Product overview
What this product covers
This product is intended for panel builders, switchgear manufacturers, electrical contractors and automation integrators. Panel text must match schematics, I/O lists, circuit numbers and equipment tags for wiring, commissioning, acceptance and fault finding. Lock the device or circuit mapping, text orientation and layout first, then confirm slots, pitch, material and any sequential numbering. Compact engraved labels for push buttons, selector switches, indicators and panel functions. Control panel labels identify individual controls where character height, colour contrast and panel spacing are tightly constrained. Complete label sets can be packed by panel reference or wiring drawing. Unlike an electrical panel nameplate, each label normally identifies one control point and is ordered as a coordinated set. Zheye cuts, marks and finishes metal plates from released drawings and variable-data files. This page presents one standard model, MP-09-AL-ANOD, in Anodized aluminium. Dimensions, processes and acceptance notes on this page refer to this representative construction.
Applications
- Control stations
- Operator panels
- Switch consoles
Buyers and teams
- panel builders, switchgear manufacturers, electrical contractors and automation integrators
Materials
- Anodized aluminium
Marking
- Mechanical engraving
- Laser engraving
- Colour filling
- Variable panel references
Installation
- Approved adhesive
- Screws
- Panel fasteners
Specifications
| Field | Documented value |
|---|---|
| Material thickness | Anodized aluminium 0.3-3.0 mm |
| Label format | Individual labels or matched panel sets |
| Text capacity | Reviewed against label dimensions |
| Profile | Rectangular, round or drawing-controlled |
| Set reference | Panel and position identifiers |
Recommended project inputs
- Control Panel Labels; cabinet or panel drawing, electrical tag list, text and units, hole or slot dimensions, mounting, colours and quantity.
- State the identified object, material/surface, available space, orientation, holes/ties/adhesive/matched tool and provide a site photo where possible.
- Provide length, width/diameter, thickness, corners/edges, holes/slots, fit tolerances and any keep-clear or no-adhesive zones.
- Supply final text, units, graphics, colour, language, serial/barcode/RFID rule, human-readable data and one approved revision; numbers shown in sample images are never treated as production data.
- State temperature and dwell, indoor/outdoor use, UV, water, oil, cleaner/chemical, abrasion, vibration, read conditions or other real exposure together with test method and pass/fail criterion.
- Provide prototype and production quantity, start/end and permitted-gap rules, grouping, packing sequence, batch documents and target delivery.
- Where regulation, certification, permit, ethics, brand authorisation or customer specification applies, provide the applicable revision and owner-approved file; a product name or image cannot replace it.
Continue with this product
Discuss Control Panel Labels
Include product code MP-09 with the project inputs that apply.
